STREAM-A 4-4-4-2
The STREAM-A 4-4-4-2 is ideal to monitor and control smaller sites like valves, wells, chemical dosing and booster pumps. It is equipped with a PLC incl. default control programs for reliable local 24/7 automation. Through the STREAMETRIC app permitted users can securely control and change setpoints remotely.
Key Aspects
• Power Fail Monitoring (Backup Battery)
• 4 Digital Inputs
• 4 Analog Inputs
• 4 Digital Outputs
• 2 Analog Outputs
• Integrated PLC
• Serial & Ethernet
• Cellular – LTE CAT 1 (Multi-Carrier)
• Real-time Data Collection & Alarms
Typical Applications
• Well Sites
• Valve Sites
Additional Information
I/O Configuration
Digital Inputs
4 (5-30VDC)
Analog Inputs
4 (5-30VDC)
Digital Outputs
4 (0-250V AC, 0-30V DC) (1 Commons)
Analog Outputs
2 (4-20mA, 0-5V, 0-10V) (1 Commons)
Power Fail Input
1 Dedicated Power Fail Input
Data Featured
Edge Computing
Local data storage and buffering, equipment runtime cycle counting, Flow totalization (pulse or analog), Local time syncing, Flow Predictions
Protocols
Communication
MODBUS TCP/RTU, OPC UA/DA, MQTT, EtherNet/IP
Hardware
Dimensions
In enclosure (H x W x D) 14.60 x 12.60 x 7.72 in, 371 x 320 x 196 mm; 14LBS
Power Information
>8h Battery Backup capabilities, Power Input: 120-240V AC, Operating voltage: 24V DC
Enclosure Type
Polycarbonate Nema 4X
